2024+ Harley Davidson® Cut In Lid Kit with Diamond Audio MS694NEOLK24 & MS69NEO Speakers + MICRO2V2 2-Channel Class D Amplifier - Premium Motorcycle Audio Upgrade for Touring & Cruising

Product Description

Features:

MS694NEOLK24 Features:

• Unrivaled Midrange Clarity: Designed for pure midrange projection, these neodymium-driven speakers deliver cutting-edge clarity and definition, ensuring your sound stays crisp and powerful at any speed.
• Built for Performance: Featuring a lightweight yet ultra-strong neodymium motor, these speakers maximize efficiency and sound output while minimizing weight.
• Extreme Durability: Designed to withstand the elements, these speakers feature rugged, weather-resistant construction for long-lasting performance.
• Plug & Play Convenience: Includes a pre-wired harness, mounting templates, and spacer rings for an easy, seamless installation.
• Upgrade your Harley Davidson® audio system with Diamond Audio’s premium midrange sound—get the MS694NEOLK24 Cut-in Lid Kit today!

MICRO2V2 Features:

• MicroV2 Series Class D 2 ohm Stable 2-Channel Amplifier
• RMS Power Rating:
• 4 ohm: 150 watts x 2 channel
• 2 ohm: 250 watts x 2 channel
• Bridged: 500 watts x 1 channel @ 4 ohm
• Total RMS power output: 500 watts
• LED Power/Protect Light
• Wired bass level remote control included
• Selectable turn-on mode (Remote, DC Offset, Signal Sensing)
• Advanced rollback and thermal protection
• Full range Class D IR chipset
• DirectFET power MOSFET output stage
• SMD technology on 4-layer glass PC board
• ICAD circuit provides superior overload protection
• Variable 12dB crossovers
• Ultra-compact and versatile
• Bluetooth receiver enabled for Diamond Audio Datura/12 Bluetooth receivers only
• Input sensitivity: 0.2 - 10 volts
• Frequency Response: 10 - 33 KHz
• Total Harmonic Distortion (THD): 0.5%
• Signal to Noise Ratio: -85 dB
• Variable high-pass filter: 40 - 400 Hz
• Variable low-pass filter: 40 - 400 Hz
• Variable Bass Boost: 0 - 12 dB
• Fuse Rating: 25A
• 8 AWG gauge amplifier wiring kit is recommended for installation
• Dimensions: 7.89" L x 4.0" W x 1.46" H

Specifications:

MS694NEOLK24 Specifications:

• Includes MS69NEO 6”x9” Midrange Speaker
• Includes Plug-n-Play Wire Harness
• 350W RMS, 700W MAX Power Handling
• Water Spray and Salt Water Resistant,100% UV Stable
• Ultra Small Neodymium Motor Structure With Max Xmax Suspension
• High Temp Injection Molded Composite Basket
• Molded,UV-Coated,Patent Pending Waterproof Cone
• Mounting Diameter: 6.38 x 9.33 in / 162 x 237 mm
• Mounting Depth: 2.28" / 58mm

MICRO2V2 Specifications:

• 2 Channel Full Range Digital Amplifier
• 250W x 2CH @ 2Ω
• 150W x 2CH @ 4Ω
• 500W x 1CH @4Ω Bridged RMS Power Output
• Input Sensitivity: 0.2-10 Volt
• Crossover Filter : 40-400Hz, 12dB Per Octave Slope
• Frequency Response: 10-33KHz
• Selectable REM / VOX / DC Turn On Modes
• Selectable X-Over: LPF / FLAT / HPF
• Dimensions: 7.89” x 4.1” x 1.46” / 200.5 x 103 x 37.2 mm
• Remote Bass Knob Included
• Disconnected RCA Input & Speaker Output Harness Kits Included
