2024+ Harley Davidson® Cut In Lid Kit with HXM69F4 Speakers & MICRO2V2 Amplifier - Diamond Audio MSHXM694LK24 Motorcycle Audio System for Harley Touring Models - Perfect for Road Trips & Custom Bike Upgrades

Product Description

Features:

MSHXM694LK24 Features:

• Seamless Integration: Precision-engineered for 2024+ Harley Davidson® models, ensuring a perfect fit and OEM-style finish that blends seamlessly with your saddlebags.
• Premium HXM69F4 Speakers: Designed for high-powered performance, these 6x9” 2-way marine-grade speakers deliver crystal-clear highs, deep bass, and dynamic sound projection, ensuring you never miss a beat on the road.
• Customizable RGB Lighting: Bring your bike to life with multi-color LED lighting, allowing you to match your sound system’s aesthetics with your ride’s overall style.
• Superior Durability: Featuring a heavy-duty steel frame and weather-resistant construction, these speakers are built to withstand the elements while delivering uncompromised audio performance.
• Effortless Installation: Includes a Plug & Play harness, custom mounting templates, and precision-fit spacer rings for an easy installation process with no modifications required.
• Upgrade your Harley Davidson with powerful, high-fidelity sound and eye-catching LED visuals. Order your MSHXM694LK24 Cut-in Lid Kit today and ride in style!

MICRO2V2 Features:

• MicroV2 Series Class D 2 ohm Stable 2-Channel Amplifier
• RMS Power Rating:
• 4 ohm: 150 watts x 2 channel
• 2 ohm: 250 watts x 2 channel
• Bridged: 500 watts x 1 channel @ 4 ohm
• Total RMS power output: 500 watts
• LED Power/Protect Light
• Wired bass level remote control included
• Selectable turn-on mode (Remote, DC Offset, Signal Sensing)
• Advanced rollback and thermal protection
• Full range Class D IR chipset
• DirectFET power MOSFET output stage
• SMD technology on 4-layer glass PC board
• ICAD circuit provides superior overload protection
• Variable 12dB crossovers
• Ultra-compact and versatile
• Bluetooth receiver enabled for Diamond Audio Datura/12 Bluetooth receivers only
• Input sensitivity: 0.2 - 10 volts
• Frequency Response: 10 - 33 KHz
• Total Harmonic Distortion (THD): 0.5%
• Signal to Noise Ratio: -85 dB
• Variable high-pass filter: 40 - 400 Hz
• Variable low-pass filter: 40 - 400 Hz
• Variable Bass Boost: 0 - 12 dB
• Fuse Rating: 25A
• 8 AWG gauge amplifier wiring kit is recommended for installation
• Dimensions: 7.89" L x 4.0" W x 1.46" H

Specifications:

MSHXM694LK24 Specifications:

• Included Rubber Gasket for HXM69F4
• Included: HXM69F4 6”x9” (4Ω) Marine Grade Speaker
• 2-Way 1 inch 25mm Titanium Dome Tweeter Speaker System (Pair)
• 150W RMS / 300W MAX MAX Power Rating
• Flush Mount Design
• Water Spray and Salt Water Resistant, 100% UV Stable
• Ultra Small Neodymium Motor Structure With Max Xmax Suspension
• High Temp Injection Molded Composite Basket
• Molded, UV-Coated, Patent Pending Waterproof Injection PP Cone
• Integrated Dream RGB LED Lighting
• Mounting Diameter: 8.64" x 6.0" / 219 x 152.5mm
• Mounting Depth: 3.15" / 80m

MICRO2V2 Specifications:

• 2 Channel Full Range Digital Amplifier
• 250W x 2CH @ 2Ω
• 150W x 2CH @ 4Ω
• 500W x 1CH @4Ω Bridged RMS Power Output
• Input Sensitivity: 0.2-10 Volt
• Crossover Filter : 40-400Hz, 12dB Per Octave Slope
• Frequency Response: 10-33KHz
• Selectable REM / VOX / DC Turn On Modes
• Selectable X-Over: LPF / FLAT / HPF
• Dimensions: 7.89” x 4.1” x 1.46” / 200.5 x 103 x 37.2 mm
• Remote Bass Knob Included
• Disconnected RCA Input & Speaker Output Harness Kits Included
